MLTI (Moonlight Tube Industries) is an ISO 14001- and 45001-certified Hastelloy C276 tube manufacturer, supplier, and exporter based in Gujarat, India. C276 tube is a low-carbon nickel-chromium-molybdenum alloy tube designated UNS N10276 and W.Nr. 2.4819. We supply Hastelloy C276 seamless tubes to ASTM B622 / ASME SB-622 and Hastelloy C276 welded and ERW tubes to ASTM B626 / ASME SB-626 in round, square, and rectangular sections. Seamless options excel in critical high-pressure applications, while welded tubes provide reliable, cost-effective performance. SB-622 sets molybdenum at 15.0–17.0%, chromium at 14.5–16.5% and tungsten at 3.0–4.5%, with nickel as the remainder and carbon limited to 0.010%. Solution-annealed C276 tubing carries a minimum tensile strength of 690 MPa (100 ksi), a minimum yield of 283 MPa (41 ksi), and 40% minimum elongation.
Our high-quality welded ERW Hastelloy tubing, manufactured by using high-frequency electric currents to fuse longitudinal alloy edges together, runs from 12.7 mm to 101.6 mm outside diameter in 19 SWG to 10 SWG walls. Additionally, our Hastelloy seamless tubes, produced from solid billets pierced into continuous tubes without weld seams for high pressure resistance, span 12.7 mm to 88.9 mm outside diameter in 19 BWG to 10 BWG walls. Reactors, scrubber circuits and bleach plants specify this nickel tubing where wet chlorine and ferric chloride attack austenitic stainless steel. Every lot is released against an EN 10204 3.1 mill test certificate.
Applicable standard, supply forms, and dimensional attributes for Hastelloy C276 tube are given in the table below.
| Parameter | Value |
|---|---|
| Applicable standards | ASTM B622 / ASME SB-622: Seamless Nickel and Nickel-Cobalt Alloy Pipe and Tube ASTM B626 / ASME SB-626: Welded Nickel and Nickel-Cobalt Alloy Tube ASTM B829: General Requirements for Nickel and Nickel Alloys Seamless Pipe and Tube |
| Supply form | Seamless, welded (ERW) |
| Sections | Round, square, rectangular |
| Outside diameter | 12.7 mm to 101.6 mm ERW (1/2″ to 4″); 12.7 mm to 88.9 mm seamless (1/2″ to 3½″) |
| Wall thickness | 1.016 mm to 3.251 mm ERW (19 SWG to 10 SWG); 1.07 mm to 3.40 mm seamless (19 BWG to 10 BWG) |
| Condition | Solution annealed and descaled |
| Finish | Annealed and pickled; bright annealed; polished to order |
| End type | Plain, cut and deburred |
| Length | Standard, random and cut lengths to order |
Hastelloy C276 chemical composition is a nickel-molybdenum-chromium system carrying tungsten and a 0.010% carbon ceiling. Composition limits for UNS N10276 tube, as per ASME SB-622, are given in the table below.
| Element | Composition, % by mass |
|---|---|
| Carbon (C) | 0.010 max |
| Manganese (Mn) | 1.0 max |
| Phosphorus (P) | 0.04 max |
| Sulphur (S) | 0.03 max |
| Silicon (Si) | 0.08 max |
| Chromium (Cr) | 14.5–16.5 |
| Nickel (Ni) | Remainder |
| Molybdenum (Mo) | 15.0–17.0 |
| Tungsten (W) | 3.0–4.5 |
| Iron (Fe) | 4.0–7.0 |
| Cobalt (Co) | 2.5 max |
| Vanadium (V) | 0.35 max |
SB-622 determines the remainder element by arithmetic difference, so nickel is reported rather than analysed directly.
UNS N10276 tube is tested at room temperature after final heat treatment and in the direction of fabrication. Certified minimums for C-276 from ASME SB-622 appear in the table given below.
| Property | Value |
|---|---|
| Tensile strength, min | 690 MPa (100 ksi) |
| Yield strength, 0.2% offset, min | 283 MPa (41 ksi) |
| Elongation in 50.8 mm (2 in.) or 4D, min | 40 % |
SB-622 sets no Hastelloy C276 hardness limit, so hardness is a reported mill value rather than an acceptance criterion.
Hastelloy C276 equivalent material designations differ by standards body, while the alloy itself stays the same. Verified cross-standard designations for the C276 tube equivalent, covering UNS, EN and DIN, are collected in the table below.
| Standard | Designation |
|---|---|
| UNS | N10276 |
| EN / W.Nr | 2.4819 |
| EN name | NiMo16Cr15W |
| DIN | DIN 2.4819 |
| Common designations | Hastelloy C-276, Alloy C-276, Nickel Alloy C276 |
Alloy C276 tube is produced by two manufacturing routes and in three cross-sections. Seamless suits high-pressure duty, while welded and ERW tube costs less per metre at the same gauge.
Hastelloy C276 seamless tube is cold-drawn from a hollow with no longitudinal weld, so no heat-affected zone acts as a corrosion initiation site. ASTM B622 / ASME SB-622 governs it, and delivery is solution annealed and descaled.
Hastelloy C276 welded tube is formed from annealed strip and seam-welded without filler metal, then solution annealed. ERW is the resistance-welded route within that family and remains our primary manufacturing method. ASTM B626 / ASME SB-626 covers this material.
Round section accounts for most alloy C276 tube demand and covers the full outside-diameter range we supply. Heat exchanger and condenser bundles, instrumentation lines and pre-bent U-bend assemblies all specify round C276 tubing.
Square box section in C276 is used for fabricated frames, guards and equipment supports inside corrosive plant enclosures, where a flat face simplifies bracket mounting. A square C276 tube is supplied against confirmed orders rather than from stock.
Rectangular section carries load about one principal axis, which suits skid frames, walkway supports and handrails in acid plant areas. Wall thickness and section dimensions are agreed at the enquiry stage.
The size chart of the C276 tube, including outside diameter, wall thickness and supply condition, has been given in the table below.
| Seamless Tube | Welded Tube | |
|---|---|---|
| Outside diameter | Up to 88.9 mm (3½″) | 3.2 mm – 88.9 mm (1/8″ – 3½″) |
| Wall thickness | 1.07 mm – 3.40 mm (19 BWG – 10 BWG) | 0.41 mm – 3.7 mm (0.015″ – 0.148″) |
| Supply condition | Solution annealed and descaled | Solution annealed and descaled |
Four industries commonly use the Hastelloy C276 in various applications, and each of them handles process media that attack chromium-nickel steels at working temperature.
Chemical plants run C276 tubing on hydrochloric, sulphuric and phosphoric acid service: reactor coils, dosing lines and acid cooler bundles. Molybdenum and tungsten stabilise the passive film under reducing conditions.
Absorber internals and quench inlets in power station scrubbers condense chloride-bearing acid at low pH. Alloy C276 tube is specified there because it resists low pH and high chloride together, a combination that pits austenitic steel.
Bleach plants dose chlorine dioxide and hypochlorite at elevated temperatures. C276 tube is specified for washer, tower and bleach liquor heater service, where resistance to wet chlorine gas is the deciding property.
Effluent treatment plants and waste incineration lines carry mixed acids of unpredictable composition. Hastelloy C276 tubing is selected for heat recovery coils and quench duty because it tolerates oxidising and reducing conditions in one circuit.
Hastelloy C276 welding is normally performed by GTAW with matching ERNiCrMo-4 filler, or autogenously on thin gauges. The 0.010 % carbon ceiling restricts carbide precipitation in the heat-affected zone; SB-622 notes that proper heat treatment during or after fabrication is necessary for optimum performance, so post-weld requirements should be agreed with the manufacturer.
Alloy C276 resists ferric and cupric chlorides, wet chlorine gas, hypochlorite and chlorine dioxide, and handles oxidising and reducing acids alike. Hot concentrated nitric acid is the exception, where a higher-chromium alloy applies.
SB-622 requires each tube to pass either a hydrostatic test or a non-destructive electric test to ASTM B829. ASME makes certification mandatory, so a manufacturer's certificate and test report accompany every lot. We add positive material identification in-house.
Hastelloy C276 tube is shipped with careful packaging and full documentation to ensure safe delivery and traceability.
As a Hastelloy supplier, we quote Hastelloy C276 tube price ranges from ₹5,000–8,500 per kg (US$52–89 per kg), because nickel and molybdenum costs move week to week. Seven variables set the figure: outside diameter, wall thickness, cut length, quantity, section and finish. Route counts too, since seamless tube carries a premium over ERW tube at the same gauge. The Hastelloy C276 price in India is confirmed at enquiry.
Buyers return to Moonlight Tubes for certified material, approved grades and stock that ships on schedule. Every order is backed by documented quality, a wide size range and delivery commitments we hold to.
Hastelloy C276 tubing is used for reactor coils, scrubber circuits, bleach plant service and incineration heat recovery, wherever chlorides or mixed acids occur.
The Hastelloy C276 ASTM standard is ASTM B622 / ASME SB-622 for seamless tube and ASTM B626 / ASME SB-626 for welded and ERW tube.
The Hastelloy C276 composition to SB-622 is 15.0–17.0% molybdenum, 14.5–16.5% chromium, 3.0–4.5% tungsten and 4.0–7.0% iron, with nickel as the remainder and carbon at 0.010% maximum.
Hastelloy C276 ERW tubes run 12.7 mm to 101.6 mm outside diameter in 19 SWG to 10 SWG walls. Seamless tube runs 12.7 mm to 88.9 mm outside diameter in 19 BWG to 10 BWG walls.
Hastelloy C276 density is 8.87 g/cm³, or 0.321 lb/in³, the figure SB-622 gives for weight calculation. That is roughly 11% heavier than austenitic stainless steel.
SB-622 doesn't set a hardness requirement for UNS N10276 tube. We report a measured value on the test certificate when the order asks for one.
The equivalent material for Hastelloy C276 tube is UNS N10276 in the United States and W.Nr. 2.4819, written DIN 2.4819 or NiMo16Cr15W, in Europe.
Yes. Hastelloy C276 tube welds readily by GTAW with ERNiCrMo-4 filler, and thin gauges weld autogenously. SB-622 advises that proper heat treatment during or after fabrication is necessary for optimum performance, so post-weld requirements should be confirmed.
No. There isn't an alloy called Inconel C276 tube, and C276 steel is a misnomer. C-276 belongs to the Hastelloy family of Ni-Mo-Cr alloys, and with only 4.0–7.0% iron it is nickel-base rather than stainless steel.
Yes. MLTI is one of the Hastelloy C276 tube suppliers in India that releases every lot against an EN 10204 3.1 certificate, supported by positive material identification records.
