304 Seamless Tube
A 304 seamless tube is manufactured without a longitudinal welded seam. ASTM A213 / ASME SA-213 covers seamless Grade 304 tube for applicable boiler, superheater and heat-exchanger service.
Stainless Steel 304 Tube Manufacturer in India
MLTI Private Limited (Moonlight Tube Industries) is an ISO 14001 and 45001 certified manufacturer, supplier and exporter of 304 stainless steel tubes based in Gujarat, India. We supply Grade 304 (UNS S30400) tube with round outside diameters from 12.7 mm to 101.6 mm. SS 304 seamless tube is manufactured to ASTM A213 for boiler, superheater, and heat exchanger service and to ASTM A269 for general service. Welded options like ERW are electric-resistance-welded cylinders manufactured to strict ASTM A269, and A554 industrial standards for quality. Both seamless and welded stainless steel tubes serve critical roles in heat exchangers, boilers, chemical plants, and architectural fabrication.
Grade 304 stainless steel contains 18.0 to 20.0% chromium and 8.0 to 11.0% nickel, with carbon limited to 0.08% maximum. The material has a minimum tensile strength of 515 MPa (75 ksi), minimum yield strength of 205 MPa (30 ksi) and minimum elongation of 35% in the annealed condition.
Our stainless steel 304 tube range includes round, square and rectangular profiles. Round tubes are available from 12.7 mm to 101.6 mm outside diameter, with wall thicknesses from 1.02 mm to 3.40 mm. Square sections start at 12 x 12 mm and rectangular sections at 13 x 25 mm. Cut-to-length service is available according to order requirements. We also hold ISO 14001 and 45001 certifications with BIS, EIL, IBR and PED approvals.
Stainless Steel 304 Tube Specifications
SS 304 tube specifications cover dimensions, manufacturing form, and applicable standards.
| Parameter | Specification |
|---|---|
| Applicable Standards | ASTM A213 / ASME SA-213 - Seamless austenitic tube for boiler, superheater and heat-exchanger service. ASTM A269 / A269M – Seamless and welded austenitic stainless steel tubing for general service. ASTM A554 - Welded stainless mechanical tubing for ornamental, structural, exhaust and similar applications. |
| Manufacturing Form | Seamless and Welded (ERW) |
| Profile | Round, Square, Rectangular |
| Round OD | 12.7 mm (1/2") to 101.6 mm (4") for standard tube; smaller diameters available as capillary tube on enquiry |
| Round Wall Thickness | 1.02 mm (19 SWG, ERW) to 3.40 mm (10 BWG, seamless) |
| Box Section Wall | 1.0 mm to 6.0 mm |
| Round Length | Up to 24 metres |
| Box Section Length | Up to 12 metres |
| Condition | Annealed |
SS 304 Tube Chemical Composition
The chemical composition of Grade 304 provides its standard combination of corrosion resistance, weldability and mechanical properties. Chromium is maintained at 18.0 to 20.0%, while nickel is controlled between 8.0 and 11.0%.
| Element | Composition (%) |
|---|---|
| Carbon (C) | 0.08 max |
| Manganese (Mn) | 2.00 max |
| Phosphorus (P) | 0.045 max |
| Sulphur (S) | 0.030 max |
| Silicon (Si) | 1.00 max |
| Chromium (Cr) | 18.0 – 20.0 |
| Nickel (Ni) | 8.0 – 11.0 |
304 Stainless Steel Tube Mechanical Properties
The mechanical requirements for ASTM A213 / ASME SA-213 Grade TP304 tube are given below.
| Property | Minimum / Maximum |
|---|---|
| Tensile Strength | 515 (75) min MPa (ksi) |
| Yield Strength, 0.2% Offset | 205 (30) min MPa (ksi) |
| Elongation in 50 mm | 35 min % |
| Hardness | 90 max HRB |
These values apply to Grade 304 tube in the specified annealed condition and should be checked against the applicable product standard for the particular order.
SS 304 Tube Equivalent Grades
SS 304 tube is identified under different designation systems depending on the country and applicable material standard.
| Standard / Country | Designation |
|---|---|
| USA (UNS) | UNS S30400 |
| Europe (EN / W.Nr.) | EN 1.4301 / X5CrNi18-10 |
| Germany (DIN) | DIN X5CrNi18-10 |
| Japan (JIS) | SUS 304 |
| India (IS) | X04Cr19Ni9 |
| China (GB/T) | 06Cr19Ni10 |
| UK (BS) | BS 304S31 |
| France (AFNOR NF) | Z6CN18-09 |
| Russia (GOST) | 08Kh18N10 |
304 Stainless Steel Tube Forms and Types
Our 304 stainless steel tubes are supplied in seamless and welded forms, along with capillary, perforated and surface-finished options where required.
02
304 Welded Tube (ERW)
304 ERW tube is formed from stainless steel strip and longitudinally welded using electrical resistance welding. ASTM A269 and ASTM A554 cover different welded tube applications.
03
304 Round Tube
304 round tubes are the standard circular profile used across general piping, fluid transport, heat exchangers, and structural applications, providing uniform strength and optimal flow characteristics.
04
304 Square Tube
304 square tubes feature equal four-sided outer profiles, widely specified for structural frameworks, equipment stands, architectural handrails, and decorative fabrications requiring high strength-to-weight ratios.
05
304 Rectangular Tube
304 rectangular tubes offer unequal four-sided geometries, making them ideal for structural applications, enclosures, and machinery frames that require specific directional load resistance and custom alignment.
Alloy 304 Tubing Sizes
We supply 304 stainless steel tube in round sections from 12.7 mm to 101.6 mm outside diameter, on wall gauges from 19 BWG to 10 BWG for seamless tube and 19 SWG to 10 SWG for ERW tube, in lengths to 24 metres.
Seamless 304 Tube Size Chart
| Size | OD (mm) | 10 BWG (3.40 mm) Weight/MTR | 12 BWG (2.77 mm) Weight/MTR | 14 BWG (2.11 mm) Weight/MTR | 16 BWG (1.65 mm) Weight/MTR | 18 BWG (1.25 mm) Weight/MTR | 19 BWG (1.07 mm) Weight/MTR |
|---|---|---|---|---|---|---|---|
| 1/2" | 12.7 | 0.78 | 0.68 | 0.55 | 0.45 | 0.35 | 0.31 |
| 5/8" | 15.875 | 1.05 | 0.89 | 0.72 | 0.58 | 0.45 | 0.39 |
| 3/4" | 19.05 | 1.31 | 1.11 | 0.88 | 0.71 | 0.55 | 0.47 |
| 1" | 25.4 | 1.85 | 1.55 | 1.21 | 0.97 | 0.74 | 0.64 |
| 1 1/4" | 31.75 | 2.38 | 1.98 | 1.54 | 1.23 | 0.94 | 0.81 |
| 1 1/2" | 38.1 | 2.91 | 2.41 | 1.87 | 1.48 | 1.13 | 0.97 |
| 2" | 50.8 | 3.98 | 3.28 | 2.53 | 2.00 | 1.52 | 1.31 |
| 2 1/2" | 63.5 | 5.04 | 4.15 | 3.19 | 2.52 | 1.91 | 1.64 |
| 3" | 76.2 | 6.11 | 5.01 | 3.85 | 3.04 | 2.30 | 1.98 |
| 3 1/2" | 88.9 | 7.18 | 5.88 | 4.51 | 3.55 | 2.69 | 2.31 |
| 4" | 101.6 | 8.24 | 6.75 | 5.17 | 4.07 | 3.08 | 2.65 |
ERW 304 Tube Size Chart
| Size | OD (mm) | 10 SWG (3.25 mm) Weight/Mtr | 12 SWG (2.64 mm) Weight/Mtr | 14 SWG (2.03 mm) Weight/Mtr | 16 SWG (1.63 mm) Weight/Mtr | 18 SWG (1.22 mm) Weight/Mtr | 19 SWG (1.02 mm) Weight/Mtr |
|---|---|---|---|---|---|---|---|
| 1/2" | 12.7 | 0.75 | 0.65 | 0.55 | 0.45 | 0.34 | 0.29 |
| 5/8" | 15.875 | 1.01 | 0.86 | 0.72 | 0.58 | 0.44 | 0.37 |
| 3/4" | 19.05 | 1.26 | 1.06 | 0.88 | 0.71 | 0.53 | 0.45 |
| 1" | 25.4 | 1.76 | 1.47 | 1.21 | 0.97 | 0.72 | 0.61 |
| 1 1/4" | 31.75 | 2.27 | 1.88 | 1.54 | 1.23 | 0.91 | 0.76 |
| 1 1/2" | 38.1 | 2.77 | 2.29 | 1.88 | 1.49 | 1.10 | 0.92 |
| 2" | 50.8 | 3.78 | 3.11 | 2.54 | 2.01 | 1.48 | 1.24 |
| 2 1/2" | 63.5 | 4.79 | 3.93 | 3.20 | 2.53 | 1.85 | 1.55 |
| 3" | 76.2 | 5.79 | 4.75 | 3.86 | 3.05 | 2.23 | 1.87 |
| 3 1/2" | 88.9 | 6.80 | 5.57 | 4.52 | 3.57 | 2.61 | 2.18 |
| 4" | 101.6 | 7.81 | 6.39 | 5.18 | 4.09 | 2.99 | 2.50 |
Standard Lengths and Cut-to-Length Service
Round 304 tube reaches 24 metres, which takes joints out of long exchanger runs. Box sections stop at 12 metres. We'll cut to a nominated length before despatch.
304 Tubing Industrial Applications
Grade 304 tube is selected for applications requiring a combination of corrosion resistance, weldability, strength and fabrication performance.
Food and Beverage Processing
304 tube is widely used in food, dairy, brewing and edible-oil processing equipment. It is suitable for many process environments involving regular cleaning and sanitation.
Chemical Processing
304 tube is used for selected chemical-processing services, cooling-water systems and dilute chemical media. More aggressive chloride environments may require a molybdenum-bearing stainless steel grade.
Heat Exchangers and Boilers
ASTM A213 / ASME SA-213 covers seamless stainless steel tube for boiler, superheater and heat-exchanger applications. Grade 304 can be selected where its corrosion and temperature resistance meet the service requirements.
Power Generation
Power-generation equipment uses Grade 304 tube in selected feedwater, condenser and auxiliary systems. Material certification and additional approval requirements are addressed according to the project specification.
Architectural Fabrication
Square and rectangular 304 tube is used for handrails, balustrades, frames, shopfronts and other architectural structures. Surface finish is often an important part of the specification.
Automotive Applications
304 tube is used in selected exhaust and fabricated automotive components because of its corrosion resistance, weldability and availability in different tube dimensions.
Oil, Gas and Renewable Energy
Grade 304 tube can be used in suitable utility, instrumentation and renewable-energy applications where the process medium and operating conditions are compatible with the material. Sour-service applications require materials specifically selected and qualified for those conditions.
304 Stainless Steel Tube Packaging and Shipping
We supply 304 stainless steel tubing in bundles with packaging selected according to the order and destination.
- Heat numbers and custom marking can be provided on request.
- Export consignments can be shipped on FOB or CFR terms through the facility.
- Export destinations include Brazil, Vietnam, Europe and Turkey.
- Mill test certificates are supplied with the applicable material.
304 Stainless Steel Tube Price
The domestic price of 304 stainless steel tube in India is approximately ₹200–280 per kg. Export prices quoted on CFR terms typically range from US$3.90 to US$4.20 per kg, the difference reflecting packing, inland freight, ocean freight and destination charges. Actual pricing depends on diameter, wall thickness, production route (seamless or welded), finish, quantity and current nickel and scrap costs.
Why Buy 304 Stainless Steel Tube From Moonlight Tubes?
Buyers return to Moonlight Tubes for certified material, approved grades and stock that ships on schedule. Every order is backed by documented quality, a wide size range and delivery commitments we hold to.
Quality Certification
01
IBR & EIL Approved
02
Why
Choose Us
03
Wide Range of Grades & Sizes
04
Timely Global Delivery
Frequently Asked Questions About 304 Stainless Steel Tube
304 stainless steel tube is a tubular product manufactured from Grade 304 austenitic stainless steel. It is a common specification for general corrosion resistance, good welding and ease of manufacturing. Its alloying ingredients are mostly chromium and nickel.
Round 304 stainless steel tube sizes are available from 12.7mm to 101.6mm outer diameter (OD) range and the wall thicknesses from 1.02mm to 3.40mm. We also provide square and rectangular profiles in conventional industrial sizes.
A 304 seamless tube is manufactured without a longitudinal seam, making it suitable for higher pressure applications. Welded tube is roll-formed from strip and longitudinally welded, offering tighter wall tolerances at a lower cost.
Seamless Grade 304 tube is commonly supplied to ASTM A213 / ASME SA-213 (boiler and heat exchanger applications) and ASTM A269 (general service). ASTM A269 (general service) and ASTM A554 (ornamental and structural applications).
Yes. AISI 304 and UNS S30400 refer to the same austenitic stainless steel grade under different designation systems. It is also equivalent to EN / W.Nr. 1.4301 and JIS SUS 304.
Yes. Square and rectangular 304 tubes are available in standard commercial sizes.
Yes. Grade 304 is easily welded using all conventional methods, including TIG (GTAW), MIG (GMAW) and high-frequency resistance welding. Welding parameters and filler materials should be matched to the wall thickness and joint configuration.
Yes. Available surface finishes include standard mill finish, 180-grit brushed/satin, polished OD, and sanitary/dairy polished OD/ID according to the order requirements.
The domestic price in India for 304 stainless steel tube generally ranges between INR 200 and INR 280 per kg. Export prices quoted on a CFR basis typically range from US$3.90 to US$4.20 per kg. Actual pricing depends on diameter, wall thickness, manufacturing route (seamless or welded), finish, quantity and current raw-material costs.
